4WD Telehandler T37.7

Telescopic lifting forklift 4×4 4WD | Maximum lifting height 7m | Loading capacity up to 3.7T | A/C cabin | Hydrostatic transmission with crab steering option

Thanks to its high-quality construction and simple technology, the compact wheel loader is an ideal choice for professional use.

The wheel loader comes standard with a 0.9 m³ bucket and features an impressive hydraulic quick-attachment system, allowing tools to be mounted in minimal time. The third hydraulic oil circuit enables the use of functional attachments such as a 4-in-1 bucket or sweeper. A variety of attachments is available from Graecus upon request.

The loader’s construction is extremely sturdy and durable. It is powered by a 99-horsepower diesel engine, with transmission through a torque converter. It has two speed levels, selected via a switch on the joystick. Reverse gear is also located on the joystick. The T37.7 loader has a lifting capacity of up to 2,700 kg and can lift loads to a height of 6,750 mm. With a 45° tipping angle, the unloading height of the standard bucket is 4,250 mm.

The loader features a spacious and comfortable cabin, equipped with heating system, fan, and windshield wiper. The cabin doors can be locked in the open position. The large glass surfaces offer excellent visibility in all directions. The suspended seat, adjustable steering wheel, MP3 radio, and rearview camera make work more comfortable, even during extended use. The full lighting system, including work lights, facilitates operation in dark conditions.

To ensure long service life, great emphasis is placed on highest quality, technically flawless construction, and sturdy design. This guarantees that you receive a durable product from Graecus, whose investment will pay off over time.

---

Key Features & Advantages

• Max load capacity: 3,700 kg

• Max lifting capacity: 2,700 kg

• Max lift height (at pin): 7,000 mm

• Dump height (standard bucket): 4,250 mm

• Breakout angle: 45°

---

Engine & Transmission

• YUCHAI 4-cylinder water-cooled diesel engine, 99 hp @ 2200 rpm – Stage V compliant with low consumption

• Hydrostatic transmission (Italian origin)

• Hydrostatic four-wheel drive (4×4) provides impressive power and flexibility, allowing it to cope even with the toughest conditions

---

Advanced Steering System

• 4-Wheel Steering – tight turning radius, perfect for confined spaces

• The steering column can be adjusted to the operator and ensures ergonomic operation without fatigue x

• Front-Wheel Steering – for high-speed travel

• Crab Steering Mode – ideal for lateral movement in tight job sites

• Automatic driving and anti-stalling control system

---

Operator Comfort & Safety

• Spacious cabin with A/C, heating, and rear-view camera

• Clear and easy-to-read multifunction display

• Ergonomic seat suspension, adjustable steering column, and MP3 radio

• Hi-Lo speed selection switch

• Euro-hitch quick coupling system with 2,300 mm digging bucket included

---

Hydraulic System & Attachments

• Standard bucket capacity: 0.9 m³

• Hydraulic quick-attachment system – change tools in seconds

• Third hydraulic line pre-installed for future attachment expansion

• Overload protection

• XCMG axles & electric transmission

• Stable load capacity regardless of steering angle

---

Compact & Agile

• Wheelbase: optimal for balance and maneuverability

• Width: 2,320 mm

• Turning radius: 2,204 mm (inner), 4,829 mm (outer)

• Articulated chassis for navigating tight spaces

• Joystick control: all functions (including telescopic boom) on one robust, sensitive joystick

• Third hydraulic line pre-installed for future attachment expansion

---

Built to Last

Constructed with robust, high-quality materials and simple yet durable technology, the T37.7 ensures long-term reliability. It’s a smart investment for professionals looking for performance and value.

• CE Certified – European safety compliance
